Optic - Lens LEICA D VARIO ELMARIT 14-50mm/F2.8-F3.5 ASPH., Mount Type:Four Thirds
mount, Max.Diameter:f78.1 , Overall Length : 102.8mm (4.05inch), Weight
490(1.07Ib)
- Configuration 16 elements in 12groups
- 2 Aspherical lenses
- F Stop Aperture Type:7 diaphragm blades / iris diaphragm , Aperture
Range:F2.8(wide) - F3.5(Tele) , Minimum Aperture:F22
- Zoom factor
- Extra Optical Zoom Max.1.5x (With Live view only. Not effective with full
pixel recording.Magnification ratio depends on the recording pixels.)
- Digital Zoom 2x, 4x (with Live view only)
- Focus Length f=14mm to 50mm (35mm film camera equivalent 28mm to 100mm) ,
Closest Focusing Distance:0.29m at all focal lengths
- 35mm SLR Equivialent Apporox. 0.32x
- Focus Area 3 points
- Focusing Area Selection:Auto / 1fixed point, left / 1fixed point, center/
1fixed point, right
- Diagonal Angle of View:75dig(W) - 24dig(T)
- Filter Winding (mm) 72.0
- Optical Image Stabilizer YES , On/Off (selectable Mode1 /2 with only DMC-L1)
Focus / Exposure - Focus Mode Type:TTL Phase Difference Detection System
- Focusing Mode:AFS/AFC/MF
- AF Detective Range:EV0-19 (ISO100)
- AF Assist Lamp: YES
- AF Lock:AFL/AEL button or Shutter button halfway pressed in AFS mode
- Exposure Exposure Mode: Program AE / Aperture Priority AE / Shutter Priority
AE / Manual
- Light Metering TTL Full Aperture Light Metering by
- 49 Zones Multi-pattern Sensing system (Optical view finder )
- 256 zone Multi-pattern Sensing system (Live view mode)
- Light Metering Mode: Intelligent Multiple/ Center Weighted/ Spot
- Metering Range:0 - 20EV with Optical view finder) , 0 - 16EV with Live view
mode (with F2.0 lens, ISO 100)
- Aperture Aperture Type:7 diaphragm blades / iris diaphragm , Aperture
Range:F2.8(wide) - F3.5(Tele) ,Minimum Aperture:F22
- Shutter Speed Type: Focal-plane shutter , 1/4000 ~ 60 and Bulb (up to approx.
8minutes) ,Remote Control: Remote control with bulb function by DMW-RSL1
(Optional)
- ISO Sensitivity Auto/100/200/400/800/1600
- White Balance Auto
- Daylight
- Cloudy
- Shade
- Halogen
- Flash
- White Set 1,2
- Color temperature setting
- White Balance Adjustment:blue/amber bias, magenta/green bias
- Color temperature setting:2500K to 10000K in 31steps
- Exposure Compensation 1/3EVStep �2EV
- Auto (AE) Bracketing 3frame, 5frame 1/3~1EV Step �2EV , AFL/AEL Button or
Shutter button halfway pressed
Feature - Self Timer 10 sec / 2sec
- Playback Mode
- Thumbnail display Yes
- Slide Show Yes
- Down Sizing Yes
- Trimming Yes
- Print Mode
- Pict Bridge Yes
- DPOF Yes
Format Images
- Format Still
- Image Formats
- RAW Yes
- JPEG Yes
|
- Image Size 4:3, 3:2, 16:9 (3:2,16:9 with
Live view only)
- 4:3 Aspect Ratio: 3136 x 2352 pixels, 2560 x 1920 pixels, 2048 x 1536 pixels
- 3:2 Aspect Ratio: 3136 x 2080 pixels, 2560 x 1712 pixels, 2048 x 1360 pixels
- 16:9 Aspect Ratio: 3136 x 1760 pixels, 1920 x 1080 pixels
- Burst Shooting Mode Burst Speed:3 frames/sec or 2 frames/sec
- Number of Recordable:6 pictures (when there are RAW file) , Unlimited
consecutive shooting (when there are no RAW file) , (depending on memory
card size, battery power, picture size, and compression)
LCD Display
- Type Low temperature Polycrystalline TFT LCD
- Monitor Size:2.5inch
- Pixels:207K pixels
- Filed of view:Approx. 100% in LIVE VIEW MODE
- LIVE VIEW: YES (LCD monitor can be used as view finder, with Live MOS sensor
set to monitor mode.
- Viewfinder Optical Yes
- Viewfinder Digital Type: Eye level Porro Mirror type Optical View Finder
- Field of View:Apporox. 95%
- Magnification:Apporox. 0.93x
- Eye point:Approx.18mm (-1[m-1])
- Diopter Adjustment:-3.0 ~ +1 [m-1]
- Focusing Screen: Fixed type
- Mirror: Quick Return Mirror
- Depth-of-Field Preview: Enabled with Aperture Preview button (with Live view
only)
- Eyepiece Shutter: Detachable
Flash System
- Build-In Flash Yes
- Flash Mode Type:TTL Built-in-Flash, GN10 (ISO100,m), Built-in Pop-up, Bounce
flash
- Auto, Auto/Red-eye Reduction, Forced On/Red-eye Reduction,Slow Sync., Slow
Sync./Red-eye Reduction, Forced On/Off
- X-Sync speed:Less than 1/160 second
- Flash synchronization:1st. Curtain Sync. and 2nd Curtain Sync. (Selectable)
- Hot Shoe:TTL Auto with FL360/FL500 (Optional)
- Flash Adjustment 1/3EVStep �2EV
Connections
- DC Input n/a
- A/V Output (NTSC--COMMA-- PAL) Yes
- USB Yes
Recording Media
- SD Memory Card Yes
- Multimedia Card Yes
- SDHC Memory Card Yes
Power
- Battery Li-ion Battery Pack (7.2V, 1500mAh) (Included)
- Charger / Adapter Input: 110-240V AC (Included)
- Battery Life Approx. 450 images (CIPA Standard with LEICA D VARIO-ELMARIT
14-50mm/F2,8-F3.5 ASPH.)
Physical Description
- Dimensions 146 x 87 x 77 mm
- Width 14.58Height 8.69Depth 7.72
- Weight 606 g
|
